Description

CARTRIDGE SPECIFICATIONS

  • Cartridge Type
    Moving Magnet
  • Output Level
    3.0 mV at 5 cm/s
  • Load Impedance
    47K Ohms recommended (Preamp MM Input)
  • Frequency Response
    12Hz to 33kHz
  • Channel Separation
    30dB at 1kHz
  • Compliance
    12 x 10-6 cm/dyne
  • Recommended Tracking Force
    2.0 grams
  • Channel Difference
    0.5dB at 1kHz
  • Total Mass
    6.5g
  • Stylus
    Elliptical Diamond
  • Cantilever Material
    Aluminum

TONEARM SPECIFICATIONS

  • Bearing
    Sapphire and Ceramic
  • Arm Tube
    Dural-Aluminum
  • Counterweight
    Eccentric
  • Adjustments
    Vertical Tracking Angle, Antiskate, Azimuth

TURNTABLE SPECIFICATIONS

  • Playback Speeds
    33-1/3 and 45 rpm
  • Motor Type
    DC Motor with Stainless Steel Brushes
  • Speed Control
    Servo System
  • Platter
    Dynamically balanced polyoxymethylene (POM)
  • Platter Bearing
    Polished and tempered steel shaft in sintered bronze bushings
  • Signal To Noise Ratio
    35dB – 40dB
  • Wow & Flutter
    0.15% – 0.25%

CONNECTIVITY

  • Stereo Outputs Unbalanced
    1

CONTROL

  • Power Control Input
    0
  • Power Control Output
    0
  • Platter Light
    N/A
  • Speed Control Fine Adjustment
    Yes

GENERAL SPECIFICATIONS

  • Dust Cover Included
    Yes

WEIGHTS & DIMENSIONS

  • Unit Dimensions (W x H x D)
    17-13/16″ (45.2cm) x 5″ (12.7cm) (6″ (15.2cm) with dust cover) x 17″ (43.2cm)
    Note: Tone Arm Height will vary depending on the type of Cartridge installed.
  • Unit Weight
    29 lbs (13.2 kg)
  • Shipping Weight
    39 lbs (17.6 kg)
