Specifications

Design
Size:16.9″ W x 13.7″ D x 4.3″ H
Weight:36.8 lbs
Finish:High Purity Aluminium
Inputs & Outputs
Audio input:Balanced XLR Line Input x1, Unbalanced RCA Line Input x 3, MM/MC (switchable) Phono Input x 1, COAX x 1, USB Audio In x1
Audio output:Subwoofer Out x 1
Power
Amplifier Output:4 Ohms200W x 4ch (800W)
Amplifier Output:8 Ohms200W x 4ch (880W)
Amplifier Output:BTL Mode On400W x 2ch (400W)
Input Sensitivity:Balanced Input2000mV
Input Sensitivity:Unbalanced (Line 1, 2, 3) Input1000mV
Input Sensitivity:Phono (MC/MM) Input5mV / 0.5mV
Impedance Input:Balanced Input44k Ohms
Impedance Input:Unbalanced (Line 1, 2, 3) Input47k Ohms
Impedance Input:Phono (MM/MC) Input47k Ohms
Bandwidth (0dBr +- 3dB / 8 Ohm):Speaker Output10Hz – 90kHz
Bandwidth (0dBr +- 3dB / 8 Ohm):H/F Speaker Output10Hz – 90kHz
Frequency Response (1W, 0 +- 1dB / 8 Ohm):Speaker Output10Hz – 90kHz
Frequency Response (1W, 0 +- 1dB / 8 Ohm):H/F Speaker Output10Hz – 90kHz
THD Measure:Balanced and Unbalanced (Line 1, 2, 3) Input0.005% (50W)
Damping Factor:Speaker and H/F Speaker Output>150
Signal to Noise Ratio (S/N):BTL / Balanced, Unbalanced / Phono MM, MC107dB / 105dB / 80dB (MM), 60dB (MC)
Impedance Output:Speaker Output53m Ohm
Subsonic Filter with On/Off Switch:-3dB50Hz
Tone Control with On/Off Switch:Bass (100Hz) / Treble (10kHz)+- 15dB
X-Over with On/Off Switch:HPF (-3dB)600Hz – 6kHz
PhonoTurnoverFlat
PhonoTurnover300Hz (+7.7dB @100Hz)
PhonoTurnover400Hz (+11.7dB @100Hz)
PhonoTurnover500Hz (+13dB @ 100Hz)
PhonoTurnover700Hz (+14.5db @ 100hz)
PhonoRoll-OffFlat
PhonoRoll-Off1.6kHz (-16dB @ 10kHz)
PhonoRoll-Off2.1kHz (-13.7dB @ 10kHz)
PhonoRoll-Off3.18kHz (-11dB @ 10kHz
PhonoRoll-Off3.4kHz (-8dB @ 10kHz)
PhonoRoll-Off6.36kHz (-5dB @ 10kHz)
Power:PowerSMPS (800W)
Power:VoltageAC100-230v, 50 / 60Hz
Audio In / Out on Rear:TriggerTrigger Voltage Can be turned On: 3.3v – 12v
Remote Control:IR Input38kHz Infrared Ray (Within 10m of operating distance)
